Announcing Telegraf 0.2.4 with MailChimp API Support

By Cameron Sparr / Product
Dec 07, 2015

Navigate to:

MailChimp is an email-marketing platform that provides a robust JSON API of metrics on email campaigns. Since Telegraf can make HTTP API calls and parse JSON, it was a natural step to allow Telegraf to parse data from services that provide metrics via an API key.

The MailChimp API provides many metrics such as emails_sent, clicks_total, and open_rate for all email campaigns via their /reports API. More details on the available MailChimp metrics are documented on the MailChimp website.

With Telegraf 0.2.4, you can now setup the mailchimp plugin to gather metrics and forward those onto InfluxDB or any other configured output sink. Below is a full configuration example that will collect MailChimp metrics and send them to a local InfluxDB instance.

# Configuration for telegraf agent
[agent]
  # Default data collection interval for all plugins
  interval = "30s"

###############################################################################
#                                  OUTPUTS                                    #
###############################################################################

[outputs]

# Configuration for influxdb server to send metrics to
[[outputs.influxdb]]
  # The full HTTP or UDP endpoint URL for your InfluxDB instance.
  urls = ["http://localhost:8086"] # required
  # The target database for metrics (telegraf will create it if not exists)
  database = "telegraf" # required
  # Precision of writes, valid values are n, u, ms, s, m, and h
  # note: using second precision greatly helps InfluxDB compression
  precision = "s"

###############################################################################
#                                  PLUGINS                                    #
###############################################################################

[plugins]

# Gathers metrics from the /3.0/reports MailChimp API
[[plugins.mailchimp]]
  # MailChimp API key
  # get from https://admin.mailchimp.com/account/api/
  api_key = "" # INSERT API KEY HERE
  # Reports for campaigns sent more than days_old ago will not be collected.
  # 0 means collect all.
  days_old = 14

The configuration above is using the days_old = 14 argument to tell Telegraf to only collect metrics on email campaigns that were sent in the past 14 days. If you set this to 0, it will collect metrics for all email campaigns.

Paste the above into a file of your choice (I’ll use ~/telegraf.conf) and insert your MailChimp API Key and run a test output, which will output your MailChimp metrics converted into the InfluxDB line protocol format.

$ telegraf -config ~/telegraf.conf -test
* Plugin: mailchimp, Collection 1
> mailchimp_emails_sent,campaign_title=MyCampaign,id=1aa2bb34c5 value=7640i 1449103122757261374
> mailchimp_abuse_reports,campaign_title=MyCampaign,id=1aa2bb34c5 value=0i 1449103122757261374
> mailchimp_unsubscribed,campaign_title=MyCampaign,id=1aa2bb34c5 value=38i 1449103122757261374
> mailchimp_hard_bounces,campaign_title=MyCampaign,id=1aa2bb34c5 value=38i 1449103122757261374
> mailchimp_soft_bounces,campaign_title=MyCampaign,id=1aa2bb34c5 value=71i 1449103122757261374
> mailchimp_syntax_errors,campaign_title=MyCampaign,id=1aa2bb34c5 value=0i 1449103122757261374
[...]

You can see from the output that the plugin will collect available metrics for each campaign, as well as collecting the industry and list stats metrics.

Telegraf can now be run and start outputting it’s metrics to InfluxDB: $ telegraf -config ~/telegraf.conf

Future Work

MailChimp is just the first of many 3rd-party APIs that we plan on supporting in Telegraf. Users are encouraged to try their hand at contributing a plugin, and we plan to support AWS Metrics soon. You can view the source for the MailChimp plugin here.
